shaft drives
Trend 3.0
An inner powerhouse
The Inboard Motor of the Trend-Line are designed for classic shaft systems or boats with existing shaft systems. They are the perfect replacement for combustion solutions and can be individually adapted to the prevailing foundation thanks to the three-dimensional motor suspension. An inboard engine that stands on its own.
€ 4.099
incl. VAT
Trend 3.0MA
Inboard Motor Trend
The highly efficient air-cooled motor is characterized by a superior performance structure. In addition, the drive has a large thrust bearing that can easily absorb the thrust of the propeller. The coupling is the central link in the power transmission from the motor to the propeller shaft. The system can be easily adapted to many different shaft types – metric and imperial dimensions. For optimal shaft alignment between the motor and propeller shaft, a special 3-dimensionally adjustable suspension system has been developed, which also has the necessary stability to absorb the thrust of the propeller shaft. Optimized mounting feet are included as vibration dampers. In order to transmit the maximum torque to the propeller and at the same time withstand the high thrust of the propeller shaft, the shaft must also be strong enough. The large stainless steel shaft meets our quality requirements exactly.
The benefits of the Inboard Motor Trend 3.0MA
State-of-the-art motor technology
3-dimensionally adjustable suspension system
Superior safety features
Large thrust bearings
Maximum smoothness
Stable drive shaft
Technical
Details
Motor
Power: 3,000W
Voltage: 36V
Control: Remote throttle
Equivalent thrust outboard: 9 HP
Weight: 25.4 kg
Download
Additional Accessories
€ 419
extension 2m € 49
extension 2m € 119
€ 469
€ 619
€ 789
from € 249
from € 399
Frequently Asked Questions
What power is required?
The Trend 3.0MA is suitable for small dinghies as well as larger boats up to approx. 45 feet. As a rule of thumb, depending on the hull shape and area (reserves against wind and waves), approx. 1-2 kW per ton of cruising weight can be assumed. For an exact interpretation, please contact a specialist dealer or Aquamot.
How long can you drive with the Trend 3.0MA?
The driving time naturally depends on the capacity and quality of the batteries.
Below are examples with the Aquamot Longlife Deep-Cycle batteries.
| Trend 3.0MA with 3 Aquamot ALS batteries 12V/260Ah | Trend 4.3MA with 4 Aquamot ALS batteries 12V/260Ah | |
|---|---|---|
| Partial load | 10 h 00 min | 10 h 00 min |
| Half load | 05 h 30 min | 05 h 30 min |
| Full load | 02 h 15 min | 02 h 15 min |
Can the battery bank be increased or decreased with the Trend 3.0 Wave Drive?
Of course, there are many ways to increase or decrease the range. In principle, however, only traction batteries should be used, which have also been designed for higher currents over a longer period (ATTENTION: no starter batteries or semi-traction batteries). In addition, a minimum capacity of at least 110Ah is recommended. All batteries should have the same capacity in order to achieve the highest possible service life. Always ask your Aquamot dealer or Aquamot about the capacity design beforehand.
What is included?
In general, the drive package includes everything (including the suspension and mounting feet, but excluding the coupling) except the batteries and the charger. This also means that the throttle/shift lever and onboard computer are included. Regarding the shaft coupling, there are two different options available that can be purchased additionally. The cable lengths are standardized (3 m main cables, 30 cm battery lead cables, and 6 m to the display and throttle/shift lever). A cable extension can, of course, be supplied for an additional charge.
What is the warranty period?
The warranty period is 2 years.
